Attributes
onsemiBrand Name
2N7002LT1GModel Number
Guangdong, ChinaPlace of Origin
N-Channel 60 V 115mA (Tc) 225mW (Ta) Surface Mount SOT-23-3 (TO-236)Description
Tape & Reel (TR) Cut TapePackaging Type
2N7002LT1GManufacturer Product Number
Manufacturer:onsemi
Description:MOSFET N-CH 60V 115MA SOT23-3
Category:Discrete Semiconductor Products Transistors FETs, MOSFETs
Part Status:Active
FET Type:N-Channel
Drain to Source Voltage (Vdss):60 V
Current - Continuous Drain (Id) @ 25°C:115mA (Tc)
Drive Voltage (Max Rds On, Min Rds On):5V, 10V
Rds On (Max) @ Id, Vgs:7.5Ohm @ 500mA, 10V
Vgs (Max):±20V
Input Capacitance (Ciss) (Max) @ Vds:50 pF @ 25 V
Power Dissipation (Max):225mW (Ta)
Operating Temperature:-65°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Package / Case:TO-236-3, SC-59, SOT-23-3
