Attributes
130grinding diameter(outer)(mm)
50grinding diameter(inner)(mm)
300max. length of workpiece (mm)
Indiaplace of origin
440Vvoltage
1800weight (kg)
power (kw):20
warranty:1 Year
core components:WORK HEAD , WHEEL HEAD,TAIL STOCK
cnc or not:Normal
grinding length(mm):300
max. weight of workpiece(kg):30
center height (mm):130
wheel size(mm):350
wheel speed (rpm):1800
table travel (x) (mm):130
roundness(mm):0.005
cylindricity (mm):0.005
brand name:PREMATO
key selling points:High-Accuracy
machinery test report:Provided
video outgoing-inspection:Provided
Centre Length (mm):300 / 500 / 800 / 1000 / 1500 / 1800 / 2000 / 2500
Centre Height (mm):130 / 150 / 180 / 200 / 225 / 250 / 300
Max. Swivel (deg.):± 6°
Speed Inf. Variable (m/min.):0.1 - 0.5
Guide ways coating:Turcite - B
Diamater:300 / 350 / 400 / 500 / 600 / 750
Width:25 to 40
Bore:127
Wheel speed:1900 - 2100
Wheel head bearings:Cartridge type, High-precision P4 grade bearings
Rapid Approach / Retraction (mm):50
Manual Feed Resolution (mm):0.005
Bearings:Imported high-precision bearings
No. of Speeds:Infinitely Variable
Speed Range:30 - 350
Swivel (deg.):0 - 90°
Spindle Nose Taper (MT):3 / 4 / 5 / 6
Infinitely Variable Speed, 3 Phase VFD:25 - 350
Centre (MT):3 / 4 / 5 / 6
Quill Travel (mm):25
