Attributes
MalaysiaPlace of Origin
anti-droneApplication
DurableFeature
400-500 MHz or customizedFrequency Range
28VWorking Voltage
≤ 3.5-4.2A (output 50W)Working current
Analog sweeping speed:Customized 50-300KHz Standard 120 KHz(8μ/s)
Output Power (Max):47±1 dBm
Gain (Max):47±1 dB
Ripple in Band:≤ 3 dB(Peak)
Bandwidth adjustment:Yes
Center adjustment:Yes
Input power (Max):≤ +10dBm(Optional (If signal source from Subscriber))
Enable control:Customize(24-28V)
Input Signal Source:Built-in high-speed noise modulation signal source
Output VSWR:≤1.5
RF output connector:SMA-Female
LED indicator light:Power ON/OFF
Dimension:117*40*18 mm
Installation Dimension:111.8*34.8*13 mm
Screw Size:M3.2
Weight:230g
Shell Material:Aluminum with natural color oxide sand blasting
