48 Cavity Water Factory Bottle Producing PET Preform Making Machine Weight Electric Plastic Injection Molding Machine
No reviews yetComplies with EU standards
Complies with EU standards
Attributes
Hydraulic, Electric, Mechanicalmachine type
630x600 mmdistance between tie bars
PETplastic processed
Horizontalstyle
High Productivitykey selling points
8+1ejector number
plasticizing capacity(g/s):543
injection weight (g):1515 g
injection rate (g/s):543 g/s
weight (kg):8700 kg
place of origin:Jiangsu, China
power (kw):76.5 kW
warranty:1 Year
mold height(mm):300 - 600 mm
ejector stroke(mm):180 mm
ejector force(kn):100 kN
theoretical shot volume(cm³):1262.5 cm³
screw speed (rpm):0 - 200 rpm
screw diameter (mm):75 mm
Screw L/D Ratio:24
open stroke(mm):520 mm
model number:HPET1500/288S7
brand name:Dawson
machinery test report:Provided
video outgoing-inspection:Provided
core components:Motor, Pump, Gear, PLC, Gearbox, Screw
Preform Neck Size:20~120mm
Preform Weight:8~100g
Cycle Time:8~15 s/shot
Hourly Output:10000~20000 pcs/h
Preform Mould Cavity:32 Cavity, 48 Cavity, 64 Cavity, 72 Cavity ...
Motor Type:Servo Motor
Raw Material:PET Resin Granuals
Machine Dimension:6.8*1.6*2.1 m
Certification:CE TUV ISO
Product:PET Preform for Beverage Bottle Production
Service
Free replacement parts & online technical support
Key attributes
machine type
Hydraulic, Electric, Mechanical
distance between tie bars
630x600 mm
plastic processed
PET
style
Horizontal
key selling points
High Productivity
ejector number
8+1
core components
Motor, Pump, Gear, PLC, Gearbox, Screw
warranty
1 Year
machinery test report
Provided
video outgoing-inspection
Provided
plasticizing capacity(g/s)
543
injection weight (g)
1515 g
injection rate (g/s)
543 g/s
weight (kg)
8700 kg
place of origin
Jiangsu, China
power (kw)
76.5 kW
mold height(mm)
300 - 600 mm
ejector stroke(mm)
180 mm
ejector force(kn)
100 kN
theoretical shot volume(cm³)
1262.5 cm³
screw speed (rpm)
0 - 200 rpm
screw diameter (mm)
75 mm
Screw L/D Ratio
24
open stroke(mm)
520 mm
model number
HPET1500/288S7
brand name
Dawson
Preform Neck Size
20~120mm
Preform Weight
8~100g
Cycle Time
8~15 s/shot
Hourly Output
10000~20000 pcs/h
Preform Mould Cavity
32 Cavity, 48 Cavity, 64 Cavity, 72 Cavity ...
Motor Type
Servo Motor
Raw Material
PET Resin Granuals
Machine Dimension
6.8*1.6*2.1 m
Certification
CE TUV ISO
Product
PET Preform for Beverage Bottle Production
Packaging and delivery
Selling Units
Single item
Single package size
25X25X25 cm
Single gross weight
12.300 kg
Lead time
Customization options
Customized logo(+ from /Min. order: 1 set)
Color customization(+ from /Min. order: 1 set)
Graphic customization(+ from /Min. order: 1 set)
View details
Product descriptions from the supplier
1 - 2 sets
$38,650
3 - 4 sets
$37,950
≥ 5 sets
$37,520
Variations
Select nowclamping force
2880KN
Customization options
Customized logo (Min. order: 1 set)
Color customization (Min. order: 1 set)
Graphic customization (Min. order: 1 set)
Supplier’s customization ability
Minor customization
Drawing-based customization
Sample-based customization
Full customization
