BoxOptronics InGaAs Photodiode 3mm 5mm 850nm 940nm VCSEL 2 5G CWDM DFB Laser TO5 TO56 Package

Name: Boxoptronics Ingaas Photodiode 3mm 5mm 850nm 940nm Vcsel 2 5g Cwdm Dfb Laser To5 To56 Package - Buy Product on Alibaba.com
Brand: Shenzhen Box Optronics Technology Co., Limited
SKU: 1601719793697
Price: 27.5 USD
Availability: InStock

No reviews yet

$27.50-36.50

Minimum order quantity: 1 unit

Select now

Specification

BLD-D-2.5G-37-B-AL

Customization options

Customized logo (Min. order: 1,000 units)

Customized packaging (Min. order: 1,000 units)

Graphic customization (Min. order: 1,000 units)

Key attributes

Mounting Type

other

Manufacturer Part Number

BLD-D-2.5G-41-B-AL

Brand Name

BOX

Description

InP based semiconductor DFB laser manufacturing technology

Type

Other

Place of Origin

Guangdong, China

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Alibaba.com order protection

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Money-back protection

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

Only orders placed and paid through Alibaba.com can enjoy free protection by

Payment & financing

4 interest-free payments with

Key attributes

Mounting Type

other

Manufacturer Part Number

BLD-D-2.5G-41-B-AL

Brand Name

BOX

Description

InP based semiconductor DFB laser manufacturing technology

Type

Other

Place of Origin

Guangdong, China

Package Type

Other

Package / Case

other

Application

CWDM optical transmission fiber communication data

Supplier Type

New original in stock

Media Available

Datasheet test report pigtail coupling parameter s

Max. Forward Voltage

1.6V (maximum rating)

Max. Reverse Voltage

2V (maximum rating)

Max. Forward Current

150mA (maximum rating)

Max. Reverse Current

1μA maximum at 2V reverse bias

Diode Type

CWDM Distributed Feedback (DFB) Coaxial Pigtail La

Voltage - Peak Reverse (max)

2V (maximum rating)

Current - Average Rectified (Io)

30-50mA average forward operating current

Diode Configuration

Single chip DFB laser with integrated backlight mo

Voltage - DC Reverse (Vr) (Max)

2V (maximum DC reverse rating)

Current - Average Rectified (Io) (per Diode)

50mA average forward current per diode

Speed

Standard industrial mass production grade

Capacitance @ Vr, F

<10pF junction capacitance @1MHz 0V bias

Current - Max

150mA maximum forward current

Resistance @ If, F

<15Ω at 50mA forward current 1MHz

Power Dissipation (Max)

300mW maximum power dissipation

Capacitance Ratio

1MHz test frequency

Configuration

other

Power - Max

other

Impedance (Max) (Zzt)

other

Product Type

InGaAs PIN Photodiode / VCSEL or DFB Laser Diode

Wavelength Range/Center

900-1650nm (PD) / 850nm, 940nm or CWDM 1270-1610nm (Laser)

Active Area / Emission Area

3 mm or 5 mm (PD) / 12 μm (VCSEL)

Key Performance (Typ.)

Responsivity: 0.9 A/W @1310nm (PD) / Output: 5-10 mW (Laser)

Bandwidth / Modulation

> 2 GHz Modulation Bandwidth (VCSEL/DFB Laser)

Operating Temperature

-40℃ to +85℃ (PD) / -40℃ to +70℃ (Laser)

Package

TO-CAN (TO5/TO56) Flat Window Hermetic Package

Primary Application

Optical Power Monitoring, Fiber Communication, Sensing

Monitor Photodiode

Integrated InGaAs Monitor PD (for DFB Laser)

Packaging and delivery

Selling Units

Single item

Single volume

0 cm³

Single gross weight

0.0 kg

Lead time
