Attributes
VERTICALtype
3, 4number of axes
0.02positioning accuracy
0.01repeatability (x/y/z) (mm)
400 mmtable travel (x) (mm)
950 mmtable travel (y) (mm)
table travel (z) (mm):500 mm
table size:800*300
cnc control system:GSK, FANUC, Mitsubishi, KND, Siemens
tool magazine capacity:12
min. time of tool change(s):7
voltage:as customer's requirement
no. of spindles:Single
key selling points:Competitive Price
warranty:1 year
machinery test report:Provided
video outgoing-inspection:Provided
weight (t):2700 T
max. table load(kg):300 kg
place of origin:Shandong, China
dimension(l*w*h):2220*1850*2350mm
spindle motor power:5.5
brand name:Chenghai
Table size:1250*360mm
X/Y/Z axis travel:400*950*500mm
Max. table loading capacity:300kg
T-slot No./width/Pitch:3/18/80mm
Spindle taper:BT40
Distance from spindle center to column:460mm
Distance between spindle nose and table:100-600mm
Spindle speed range:200-6000/8000rpm
X/Y/Z axis rapid movement speed:10/10/8 M/min
Power(W):5.5kw
