Custom HDI PCB Printed Wiring Circuit Board Multilayer Buried Blind Via PCB Design Prototype Fabrication PCBA Assembly Service

Store rating:5.0

(2 reviews)

Shenzhen Keshijia Electronic Precision Co., Ltd.

2 yrs

CN

Attributes

Max. 32 layersNumber of Layers

Green, Blue, Black, Red, Purple, White , etcSolder Mask

HDI PCBType

0.2 mm - 5.0 mmBoard Thickness

Max. : 510 mm X 600 mmBoard Size

KHD01Model Number

Place of Origin:Guangdong, China

Brand Name:KSJ or OEM

Base Material:Fr4 , F4B, PTFE, PI, PET, Metal Base , Ceramics

Copper Thickness:0.5 oz - 20 oz

Min. Hole Size:Laser 0.10 mm Mech 0.20 mm

Min. Line Width:3 mil (0.075 mm)

Min. Line Spacing:3 mil (0.075 mm)

Surface Finishing:ENIG, HASL, OSP, Carbon Ink, Immersion Tin

Product name:Custom HDI PCB

Buried / Blind via:Support

Hole Plugging:Support

Microvia:Support

HDI Build-up Orders:First-order HDI, Second-order HDI , Third-order HDI

Full Service:PCB Design , PCB Manufacturing and PCBA Assembly

Certificate:ISO14001, CE/RoHS, IATF16949, UL, CQC , ISO13485

Warranty:1-3 years

Customizable Design Options: Our custom HDI wiring board multilayer PCBs offer a wide range of design options, including board thickness (0.2 mm - 5.0 mm), copper thickness (0.5 oz - 100 oz), and layer count (1-32 layers), catering to diverse user requirements.
High-Quality Certifications: Our products are certified by ISO9001, CE/ROHS, IATF16949, and UL, ensuring compliance with international quality and safety standards, meeting the expectations of discerning customers.
Variety of Surface Finishing Options: We provide multiple surface finishing options, including ENIG, HASL, OSP, carbon ink, and immersion tin, allowing users to choose the best fit for their specific application.
Support for Complex Designs: Our team provides support for PCBA reverse engineering, OEM/ODM services, buried/blind via capabilities, and finish hole tolerance (npth: 0.025 mm, pth: 0.05 mm), making it an ideal choice for intricate designs.
Large Board Size and Precision: Our HDI PCBs can accommodate board sizes up to 800 mm x 800 mm, with a minimum line spacing of 3 mil (0.075 mm) and line width of 3 mil (0.075 mm), ensuring precise and reliable performance in electronics devices.
