Attributes
Aluminum or DKP steel (blades), High-grade extruded aluminum (frame)Material
Ceiling MountedInstallation
Hospitals, Shopping malls, Stores, Conference rooms, Offices, Bank branches, Commercial HVAC systemsApplication
Modern, Minimalist, FunctionalDesign Style
1 YearWarranty
Optional accessories: Parallel blade dampers, Electrostatic powder-coated surface, Removable inner blades for easy maintenance, Durable and corrosion-resistant construction, Customizable 1-way, 2-way, or 3-way air deflection, 4-way air deflection (standard)Feature
Shape:Square
Project Solution Capability:graphic design, 3D model design, total solution for projects
After-sale Service:Online Support
Length:150 mm to 525 mm
Heating Element:N/A (No heating element as it is a diffuser)
Place of Origin:Turkiye
Brand Name:ICEMAC
Material Standard:High-grade Extruded Aluminum (AISI 6063-T5) / DKP Steel
Airflow Deflection:4-Way Standard (Customizable to 1-Way, 2-Way, or 3-Way)
Optional Accessories:Parallel Blade Dampers, Opposed Blade Dampers, Plenum Box, Subframe
Effective Area Range:0.021 m² to 0.158 m²
Installation Options:Standard Screw Mounting, Concealed Screw, Plate Spring, Subframe
Air Volume Capacity:150 m³/h to 2500 m³/h
Customization Capability:Size, Color, and Air Deflection Customization Available
Certifications:ISO 9001:2015, ISO 14001:2015, ISO 45001:2018
