Attributes
Customizedvoltage
280Clamping Force (kN)
70 kg/houtput (kg/h)
Jiangsu, Chinaplace of origin
Automaticautomation
85power (kw)
weight (t):12
video outgoing-inspection:Provided
machinery test report:Provided
core components:Bearing, Gearbox, Motor, Pressure Vessel, Pump
plastic processed:PP.PE,HDPE,HMWHDPE....
brand name:Sino-Tech
dimension(l*w*h):3.43*1.77*2.58
plc brand:Mitsubishi
Screw L/D Ratio:26
screw diameter (mm):70 mm
No. of Screw Heating Zone:3
screw heating power(kw):12.7 kW
extruder motor power(kw):30 kW
mold platen size(width)(mm):440 mm
mold platen size(height)(mm):420 mm
air pressure(mpa):0.8 MPa
air comsumption(m³/min):0.4 m³/min
die head heating power(kw):25 kW
key selling points:Energy Saving
warranty:12months
Blow Moulding Type:Extrusion Blow Moulding
After-sales Service Provided:Engineers available to service machinery overseas
Plasticizing capacity:70kg/H
Screw diameter:70mm
Platen dimension:440*420mm
Platen distance:148-508mm
Microcomputer Control System:MITSUBISHI
Maximum Application size:5L
Mold Material::P20, 2316, S136H, Aluminum with beryllium copper
Marketing Type:New Product 2023
Selling Units:Single item
Single package size:350X260X230 cm
Single gross weight:4500.000 kg
