Ft-Opto FQXY110AM Monocular Automatic XY Moving High Precision PC Connect Microscope Working Stage 1kG Capacity IP53 Rated
Store rating:4.9
(123 reviews)
Attributes
Monocular Microscopetype
Otherillumination
Manual FocusFocus Type
±15dDioptric Adjustment
1920*1080camera resolution
YesExternal Display Support
place of origin:Guangxi, China
IP Rating:IP53
model number:FQXY110AM
customized support:OEM, ODM
warranty:1 year
size:LxW 247x208mm
Travel distance:X,0-110mm Y,0-110mm
Measurement accuracy:(3+0.2L)μm
Repeatability accuracy:2μm
Maximum bearing capacity:1kG
Fastest moving speed:8.5 mm/s
Fine focus Resolution:0.1μm
Power adapter:24V5A
control:Controller/ PC connect with communication protocol
Service
Free replacement parts & online technical support
Key attributes
type
Monocular Microscope
illumination
Other
Focus Type
Manual Focus
Dioptric Adjustment
±15d
camera resolution
1920*1080
External Display Support
Yes
IP Rating
IP53
warranty
1 year
customized support
OEM, ODM
place of origin
Guangxi, China
model number
FQXY110AM
size
LxW 247x208mm
Travel distance
X,0-110mm Y,0-110mm
Measurement accuracy
(3+0.2L)μm
Repeatability accuracy
2μm
Maximum bearing capacity
1kG
Fastest moving speed
8.5 mm/s
Fine focus Resolution
0.1μm
Power adapter
24V5A
control
Controller/ PC connect with communication protocol
Packaging and delivery
Selling Units
Single item
Single package size
35X40X25 cm
Single gross weight
6.000 kg
Lead time
Product descriptions from the supplier
Warning/Disclaimer
This product has acquired the relevant product qualification(s)/license(s) of certain applicable country/countries.View more
FREE shipping capped at $20
1 - 49 pieces
$2,727
>= 50 pieces
$1,909
*Taxes and import charges will be calculated at checkout
Variations
Select noweyepiece magnification: 1X
1X
magnification: 10-200X
10-200X
objective magnification
1X
