High Cost-Effective Digital Ultrasonic Flaw Detector with 0-15000mm Measuring Range and 40dB Dynamic Range

No reviews yet
$1,050
Minimum order quantity: 1 piece
Select now

Color

Red

Measurement Range

HT-680

Key attributes

Far-Field Resolution

34 dB

Horizontal Linearity Error

≤1%

Type

Ultrasonic Flaw Detector

Vertical Linearity Error

≤2%

Field of View

Other

Flaw Detection Video

Yes

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Alibaba.com order protection

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Money-back protection

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

Only orders placed and paid through Alibaba.com can enjoy free protection by

Payment & financing

4 interest-free payments with

Key attributes

Far-Field Resolution
34 dB
Horizontal Linearity Error
≤1%
Type
Ultrasonic Flaw Detector
Vertical Linearity Error
≤2%
Field of View
Other
Flaw Detection Video
Yes
Magnification
Other
Model Number
HT-680
Brand Name
HANTAI
Place of Origin
Beijing, China
Working Voltage
Other
Measuring Range
0 to 15000 mm, at steel velocity
Material Velocity
1000 to 20000m/s
Dynamic range
more 40dB
System Linearity
Horizontal: +/-0.2% FSW
Resolving Power
more 40dB
Sensitivity Leavings
more 50dB(Deep 200mm*Diameter2 flat-bottomed hole)
Probe Delay/Zero Offset
0 to 99.99us
Display Delay
-20 to 3400 us
Pulse Energy
100V, 200V, 250V, 300V, 500V selectable
Pulser
Tunable Wave Pulser

Packaging and delivery

Selling Units
Single item
Single package size
45X38X25 cm
Single gross weight
5.500 kg

Lead time
