High Efficiency Panel Fan With Direct Drive EC Motor And Customizable Voltage For Versatile Use

No reviews yet

Multispecialty Supplier

1 yr

US

Attributes

380-480VVoltage

PlasticMaterial

750RPMspeed

Wall-Mounted Axial FanType

3 Yearswarranty

38INBlade Diameter

Power Source:Electric

blade material:Stainless Steel

place of origin:United States

bearing type:Ball Bearing

customized support:OEM, ODM

brand name:BONAWIND

after-sales service provided:Online support

Product Name:38'' Panel fan

Frame Size:44.1''*44.1''*12''

Frame Material:High-strength double-layer PE

Installation:60mm pipe installation

Power:3PH/380-480V/50-60HZ

Max Airflow:15882CFM

Air Speed:4.2m/s- 6m to the fan

Blade Material:4pcs 304 stainless steel(1mm thickness)

Blade:riveted in one time, good balance and low noise

Motor:Outer rotor permanent magnet brushless DC motor

Rotation Speed:750r/min

Current:0.6A

Input Power:300w

Air Volume/W:53CFM

Protection Level:IP55

Noise:≤69dB

Key attributes

Voltage

380-480V

Material

Plastic

speed

750RPM

Type

Wall-Mounted Axial Fan

warranty

3 Years

Blade Diameter

38IN

Power Source

Electric

blade material

Stainless Steel

bearing type

Ball Bearing

customized support

OEM, ODM

after-sales service provided

Online support

place of origin

United States

brand name

BONAWIND

Product Name

38'' Panel fan

Frame Size

44.1''*44.1''*12''

Frame Material

High-strength double-layer PE

Installation

60mm pipe installation

Power

3PH/380-480V/50-60HZ

Max Airflow

15882CFM

Air Speed

4.2m/s- 6m to the fan

Blade Diameter

38''/0.96m

Blade Material

4pcs 304 stainless steel(1mm thickness)

Blade

riveted in one time, good balance and low noise

Motor

Outer rotor permanent magnet brushless DC motor

Rotation Speed

750r/min

Current

0.6A

Input Power

300w

Air Volume/W

53CFM

Protection Level

IP55

Noise

≤69dB

Packaging and delivery

Selling Units

Single item

Single gross weight

31.000 kg

Product descriptions from the supplier

Minimum order quantity: 1 piece

$715
