Attributes
Industrial Coolingapplication
Otherpressure
OBM, ODM, OEMcustomized support
1 Yearwarranty
Gyeonggi-do, South Koreaplace of origin
Electricpower source
structure:Other
model number:WNA-0380SKA
Applicable temperature:-20°C ~ max 155°C
cable length:1 m, 2 m, 3 m, 4 m, 5m
Control Method:Inverter
Impeller Material:SS316
Inlet Height:145mm
Max Pressure:11.9
motor:Three-Phase Motor
outlet size:55mm
Outlet Type:Universal Style
Sealing Material:Stainless Steel
Surface Treatment:Ceramic Coating
Material:Stainless Steel
Speed Control range by inverter:50-200Hz
Speed Control:by inverter
Insulation Class:Class F ( 155°C)
Motor Number of poles:6
Motor Rated voltage:214 [V]
Motor Power at rated rpm:2.2 [kW]
Motor rated Current:8.4 [A]
Motor Rated frequency:150 [Hz]
Motor Rated torque:6.80 [Nm]
Motor Efficiency:92.25 [%]
Motor Power factor:0.76[%]
Motor Efficiency class:IE4
