Kassel Industrial Robot Workstation 7-9 Axis Core Motor Engine Collaborative Automation Beam Robotic Welding System 0.5mm

No reviews yet
$6,800
1-2 sets
$6,200
3-4 sets
$5,200
≥5 sets
Select now

model number

Welding workstation
Customization options
Packaging (Min. order: 1 set)
dimension(l*w*h) (Min. order: 1 set)

Key attributes

Drive Type

servo-electric

core components

Bearing, Gear

voltage

380 V, 110 V, 220 V

power(w)

1 kW

machinery test report

Provided

Warranty

1 Year

At a glance

  • 7-Axis To 9-Axis Freedom: The high degree of freedom, ranging from 7 to 9 axes, allows for precise and flexible movement, making it suitable for complex and varied welding tasks.

  • Visual Accuracy ≤0.5mm: High visual accuracy ensures precise positioning and alignment, leading to high-quality welds and reduced rework.

  • X-Axis Speed ≥20m/min: The fast X-axis movement speed enhances productivity by reducing the time required for positioning and welding operations.

  • Arm Range R=2010mm: A wide range of motion for the robot's arm allows for a larger working area, enabling the handling of large and complex workpieces.

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Key attributes

Drive Type
servo-electric
core components
Bearing, Gear
voltage
380 V, 110 V, 220 V
power(w)
1 kW
machinery test report
Provided
Warranty
1 Year
video outgoing-inspection
Provided
production capacity
10
place of origin
Shandong, China
weight (kg)
1000
brand name
Kassel
application
Enhance welding quality and consistency
Number of Jaws
4
Degree of freedom
7-axis,8-axis,9-axis
The range of motion of the robot's arm
R=2010mm
Length of the slide rail
6M/8M/12M/14M/16M
Visual accuracy
≤0.5mm
Scan frame rate
2000 frames /sec
The X-axis movement speed
≥20m/min
Cantilever Y-axis movement speed
≥12m/min
Column Z-axis moving speed
≥8m/min

Packaging and delivery

Selling Units
Single item
Single volume
0 cm³
Single gross weight
0.0 kg

Lead time

Customization options

Packaging(+ from /Min. order: 1 set)
dimension(l*w*h)(+ from /Min. order: 1 set)
