Attributes
DieselPower Type
JIUHE/JH/CustomizeBrand Name
240MMax. vertical conveying distance
800mMax. horizontal conveying distance
80M³/HProductivity
Shandong, ChinaPlace of Origin
Warranty:1 Year
UNIQUE SELLING POINT:High operating efficiency
Core Components:Motor, Bearing, Gearbox, Engine, PLC
Weight:6600
Dimension(L*W*H):6600 X 1930 X 2190mm
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Max. theoretical delivery pressure:15.7 MPa
Hopper capacity:600 L
Output opening diameter:150 mm
Type of Hydraulic oil circuit:Open circuit
Max. delivery frequency:26 times/min
Distribution valve type:Stube valve
Rated rotation speed:1480 r/min
Hoisting height:1450 mm
Allowed max dia.of aggregate:Pebble50, crushed stone 40
Applicable Industries:Building Material Shops
