Low Profile Flat Wire Air Core Inductor High Current Inductor for Audio Speaker Crossover High Q Factor OEM ODM Factory

No reviews yet
$2.10
5-99 pieces
$1.40
100-999 pieces
$0.70
1,000-9,999 pieces
$0.35
≥10,000 pieces
Select now

Specification

-- Ultra-high current Group (120A-200A)
0.10uH/200A/DCR<=0.5mOhm/H-Mnt/D~32mm
0.20uH/200A/DCR<=0.7mOhm/H-Mnt/D~32mm
0.20uH/160A/DCR<=0.8mOhm/V-Mnt/D~30mm
0.30uH/160A/DCR<=0.9mOhm/H-Mnt/D~28mm
0.50uH/160A/DCR<=1.0mOhm/H-Mnt/D~26mm
0.50uH/160A/DCR<=1.2mOhm/V-Mnt/D~26mm
0.80uH/160A/DCR<=1.2mOhm/H-Mnt/D~26mm
1.00uH/160A/DCR<=1.5mOhm/H-Mnt/D~28mm
+88
Customization options
Customized logo (Min. order: 1,000 pieces)
Customized packaging (Min. order: 1,000 pieces)
Graphic customization (Min. order: 1,000 pieces)

Key attributes

Model Number

Customized / Std Series Available

Type

Edgewise Winding / Flat-wise Winding Inductor

Brand Name

Speed

Application

Charger/Inverter/Solar/Audio/Auto/Power/Storage

Rated Power

Application Dependent (Current Rated)

Mounting Type

Through-Hole Solder / Bolt-on Terminal

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Alibaba.com order protection

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Money-back protection

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

Only orders placed and paid through Alibaba.com can enjoy free protection by

Payment & financing

4 interest-free payments with

Key attributes

Model Number
Customized / Std Series Available
Type
Edgewise Winding / Flat-wise Winding Inductor
Brand Name
Speed
Application
Charger/Inverter/Solar/Audio/Auto/Power/Storage
Rated Power
Application Dependent (Current Rated)
Mounting Type
Through-Hole Solder / Bolt-on Terminal
Place of Origin
Guangdong, China
Mfg. Date Code
Per Order Batch
Brand
OEM / ODM Supported
Supplier Type
Manufacturer Direct Supply
Cross Reference
Custom Design / OEM Parts
Tolerance
Inductance +/-10% Std, +/-5% Available
Operating Temperature
-40.C to +180.C (Class H)
Package Type
Bare Coil / Custom Tray
Resistance Tolerance
DCR as Max Value Specified (mOhm)
Temperature Coefficient
Near Zero
Resistance
DCR 0.5-50mOhm, AC Z Freq. Dependent
Media Available
Datasheet / Drawings / RoHS / Test Report
Frequency - Self Resonant
SRF 10 MHz Typical (Model Dependent)
Features
High Current / Ultra-Low DCR / No Saturation
Height - Seated (max)
Custom / Typically 3mm - 50mm
Function
HF Filtering/Resonance/Energy Storage/Choke/Boost
Inductance
Custom / 0.1uH - 50uH Typical
Q @ Freq
High Q 80 at Optimal Frequency
Package / Case
Bare Coil / Varnish Dipped / Epoxy Coated
Size / Dimension
Outer D 15-150mm (Round/Square/Oval)
Heigh
Custom / Typically 3mm - 100mm
Number of Coils
Custom / Typically 2T - 50T
Inductance - Connected In Parallel
N/A (Single Coil Element)
Inductance - Connected In Series
N/A (Single Coil Element)
Current Rating - Parallel
N/A (See Rated Current Below)
Current Saturation - Parallel
No Saturation (Air core does not saturate)
Current Saturation - Series
No Saturation (Air core does not saturate)
DC Resistance (DCR) - Parallel
Same as DCR (Single Coil)
DC Resistance (DCR) - Series
Same as DCR (Single Coil)
Shielding
Non-shielded
Material - Core
None (Air Core, No Magnetic Material)
Current Rating (amps)
5A - 200A RMS (Model Dependent)
Current - Saturation
No Saturation (Air Core, Fully Linear)
DC Resistance (DCR)
0.5m - 50mOhm (Model Dependent)
Core Type & Magnetic Property
Air Core, No Magnetic Material - Zero Saturation, Linear Inductance
Winding Technology & Wire Type
Flat Wire Edge-Wound Air Core Coil, Rectangular Copper, Ultra-Low DCR
Mounting & Installation Method
Through Hole DIP technology for high stability and easy assembly
Temperature & Insulation Class
-40.C to +180.C Class H, Class 200C Rated Wire
Electrical Performance Highlights
Ultra-Low DCR 0.5mOhm, High Q 80, No Core Losses - Air Coil Inductor
Shape & Form Factor Options
High quality Unshielded air core coil with CE Certified reliability
Application & Industry Coverage
EV Charging / Solar & Storage Inverter / Audio Crossover / RF
Compliance & Certification
RoHS Compliant, UL Recognized Class H 180C, 100% Tested (L/DCR/SRF)
Customization & Engineering Support
Custom Flat Wire Air Core Coil / Air Coil Inductor - OEM ODM
Packaging & Export Readiness
Anti-Static Tray/Foam Carton, Custom Pack, Sea & Air Export
