Attributes
TWOWINBrand Name
T808Model Number
Guangdong, ChinaPlace of Origin
Desktop and wall mountedMounting Type
NVIDIA Jetson Orin Nx SeriesDescription
in-vehicle / traffic / logistic / sanitation truckApplication
Series:jetson orin NX
Features:NIVIDA
Size / Dimension:275mm*177.3mm*76.5mm
Al computing power:70TOPS/100TOPS
CPU:CPU 1.5MB L2 +4MB L3,2 GHz6-Core ARM Cortex-A78AE v8.2
GPU:1024- Core NVIDIA Ampere architecture GPU with 32 TensorCore,765 MHz
RAM:8GB 128-bit LPDDR5 102.4GB/s 16GB 128-bit LPDDR5 102.4GB/s
Ethernet:4x M12 Gigabit Ethernet port (independent IP), 4x M12 (shared IP)
USB:4x USB3.0 Type-A Video output: 1x HDMI2.0 compatible with 1.4
CAN:1x CAN,lx SPI-CAN(optional)
GPIO:(3.3V@1mA,With isolation function )4x GPIO (IN), 4x GPIO (OUT)
M.2:1xM.2 Key M (PCIE NVME 2280 SSD)
temperature:-20℃-60℃
