Attributes
16:9, Otheraspect ratio
Indoorapplication
800brightness
IP31ip rating
3 mmPixels
-20℃~60℃Operating Temperature
Screen Type:LED
warranty:2 Years
place of origin:Guangdong, China
Remote Device Management:No
specification:LED cabinet
use:LED video wall
model number:V1.95
brand name:Aistartech
Content Management System:Yes
Control Method:Computer
Dimensions:500*250*33, 750*250*33, 1000*250*33, 500*500*33, 750*500*33, 1000*500*33
Display Function:Animation
function:SDK
Material:Die Casting Aluminum
media available:Other
panel brand:Aistartech
Pixel Density:262144
Pixel Pitch:1.95
supplier type:Original Manufacturer, ODM, OEM
Usage environment:Indoor
view angle（h/v）:160°
Voltage:100-110 V / 200-240 50-60 Hz
Pixel Pitch:V1.95
LED Type:SMD1515
Physical density(Dot/㎡):262144
Module resolution:128*128
Module dimension(mm):250*250
Panel size(mm):500*250*33/750*250*33/1000*250*33/500*500*33/750*500*33/1000*500*33
Module quantity(W*H):2*1/3*1/4*1/2*2/3*2/4*2
Panel resolution:256*128/384*128 512*128/256*256 384*256/512*256
Maintenance:Front access
Cabinet material:Die cast aluminum
Color temperature(K):5000-12000 Adjustable
Viewing angle(V/H):160°/160°
Frame frequency:50/60
Drive mode:1/32 Scan
Gray level(bit):14/16 Optional
Refresh rate(Hz):3840
Max. power consumption((W/㎡):350
Avg. power consumption((W/㎡):100-200
