Attributes
Generalapplication
PN16Operational Pressure Range
3/8''-1.5'' DN 10...DN 40port size
Electricpower
Controlstructure
OEMcustomized support
place of origin:Germany
model number:VVP45.. VXP45.. VMP45..
brand name:Siemens
media:Water
temperature of media:Medium Temperature, Normal Temperature
Voltage:AC 230 V/ AC/DC 24 V
warranty:1 years
Body material:bronze
Positioning signal:3-position/DC 0...10 V
Nominal stroke:5.5 mm
Connection method:BSPP
Working temperature:1...110 °C
Positioning force:200 N/300 N
Valve flow characteristic:equal percentage/linear
Operating voltage:AC 230 V/ AC/DC 24 V
Leakage rate:0...0.02 % of kvs-value
