Attributes
220Vvoltage
Light Dutymachining capacity
3number of axes
4no. of spindles
Nonetool post stations
100 mmmax. length of workpiece (mm)
key selling points:Automatic
repeatability (x/y/z) (mm):±0.002
positioning accuracy (mm):±0.002
warranty:2 Years
type:Horizontal
machinery test report:Provided
video outgoing-inspection:Provided
max. weight of workpiece(kg):30
travel (x axis)(mm):54
travel (z axis)(mm):76
place of origin:Guangdong, China
width of bed (mm):400 mm
dimension(l*w*h):84*47*38cm
brand name:sihao
model number:210ZXJCC000000001V2
weight:77
cutting torque:2.5
Swing Over Bed:8-1/4inch (210 mm)
Cross Slide:4-5/8inch (117 mm)
Distance Between Centers:15-3/4inch (400 mm)
Spindle Speed Ranges:Low 50-1250, high 100-2500 RPM
Metric Threads:0.5-3.0 mm
Footprint:31-1/2 x 10-1/2 inch
Max. Swing Diameter:210mm
Power (kW):0.75
Spindle Bore(mm):21 m'm
Max. Spindle Speed (r.p.m):2250
