Value Air Conditioning Refrigerant Vacuum Pump Rotary Vane Vacuum Pump Single Stage Air Pump FY-2C-N
No reviews yet
Attributes
HVACapplication
oil-lubricated, air-cooledstructure
3.6 m³/hMax Flow Rate
0.1 -10 BarMax Pressure
Electricpower source
oilsChemical Compatibility
pressure:High Pressure
customized support:None
place of origin:Zhejiang, China
warranty:1 Year
model number:FY-2C-N
brand name:Value
Applicable temperature:0-40
cable length:1 meter
Connection Type:Welding
Control Method:Manual Control
Discharge Pipe Size:1/2 in
Displacement:7.2 m³/h
Dwell time:3 Hours
Filter material:Non-Woven Fabric Filter Core
Flow Meter Specification:7.2 m³/h
Flow Rate:7.2 m³/h
Hardness:80Shorea
horsepower:0.20 HP
Impeller Material:High-strength aluminum alloy
Import Size:Dn25
Inlet Height:140mm
Membrane material:Not applicable
motor:Single-phase capacitor running motor
outlet size:12 mm / 0.472"
Outlet Type:Barb
Outlet Water Oil Content:5mg/l
Sealing Material:NBR
suction head:Ultimate Vacuum: ≤2 Pa
Surface Treatment:Clear coating + black powder coating
Material:Die-cast aluminum alloy
Voltage:220V-50Hz
Size:318x124x234 mm
Motor power:220V~/50Hz
Pumping rate:7.2 m³/h
Inlet Port:7/16"-20UNF
Weight:8.1kg
Oil capacity:250 ml
Critical pressure(Pa):2 Pa
Keyword:bomba de vacio refrigeracion
Main material:Aluminum alloy pump body carbon fiber rotor blades
Key attributes
application
HVAC
structure
oil-lubricated, air-cooled
Max Flow Rate
3.6 m³/h
Max Pressure
0.1 -10 Bar
power source
Electric
Chemical Compatibility
oils
Sealing Material
NBR
Impeller Material
High-strength aluminum alloy
Applicable temperature
0-40
outlet size
12 mm / 0.472"
Import Size
Dn25
Connection Type
Welding
suction head
Ultimate Vacuum: ≤2 Pa
Outlet Type
Barb
Discharge Pipe Size
1/2 in
Inlet Height
140mm
Flow Rate
7.2 m³/h
Displacement
7.2 m³/h
Material
Die-cast aluminum alloy
Control Method
Manual Control
motor
Single-phase capacitor running motor
Surface Treatment
Clear coating + black powder coating
Membrane material
Not applicable
warranty
1 Year
customized support
None
cable length
1 meter
horsepower
0.20 HP
pressure
High Pressure
Dwell time
3 Hours
Hardness
80Shorea
Flow Meter Specification
7.2 m³/h
Filter material
Non-Woven Fabric Filter Core
Outlet Water Oil Content
5mg/l
model number
FY-2C-N
place of origin
Zhejiang, China
brand name
Value
Voltage
220V-50Hz
Size
318x124x234 mm
Motor power
220V~/50Hz
Pumping rate
7.2 m³/h
Inlet Port
7/16"-20UNF
Weight
8.1kg
Oil capacity
250 ml
Critical pressure(Pa)
2 Pa
Keyword
bomba de vacio refrigeracion
Main material
Aluminum alloy pump body carbon fiber rotor blades
Packaging and delivery
Selling Units
Single item
Lead time
1 - 9 pieces
$75
≥ 10 pieces
$72
Variations
Select nowFlow Rate: 50 L/min
50 L/min
maximum head: None
None
type: oil-lubricated rotary vane vacuum pump
oil-lubricated rotary vane vacuum pump
voltage
220 V
Supplier’s customization ability
Minor customization
Drawing-based customization
Sample-based customization
Full customization
