Attributes
MalaysiaPlace of Origin
anti-droneApplication
DurableFeature
400-500 MHz or customizedFrequency Range
28V; 30V for 5.2G,5.8GWorking Voltage
≤ 7-9A (output 100W)Working current
Analog sweeping speed:Customized 50-300KHz Standard 120 KHz(8μ/s)
Output Power (Max):50±1 dBm
Gain (Max):50±1 dBm
Ripple in Band:≤ 3 dB(Peak)
Bandwidth adjustment:Yes
Center adjustment:Yes
Input power (Max):≤ +10dBm (Optional (If signal source from Subscriber))
Enable control:Customize(24-28V)
Input Signal Source:Built-in high-speed noise modulation signal source
Output VSWR:≤1.5
RF output connector:SMA-Female
LED indicator light:Power ON/OFF
Dimension:150*80*22 mm
Installation Dimension:144.3*74*22 mm
Screw Size:M2.5
Weight:800g
Shell Material:Aluminum with natural color oxide sand blasting
